| Drill Bit Size / Cutting Diameter (DC) | 8.2 mm | Shank Type | Central tapered |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 8.2 mm | Cutting Edge Material | Carbide |
| Coating | Uncoated | Tool Type | Deep Hole / Gun Drill |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | | Grade | G2F |
| Application | | Gundrill | | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 19.05 mm | Usable Length (LU) | 1167 mm |
| Head Length (LH) | 25 mm | Length Chip Flute (LCF) | 1170 mm |
| Coolant Supply Property (CSP) | Coolant Thru | Overall Length (OAL) | 1250 mm |
| Point Angle (SIG) | 130 Degrees | Body Material | Carbide |
| Shank Length (LS) | 70 mm | Unit | M |
Product Features
| Family Description | Brazed Gundrills | COO | JAPAN |
Shipping Info
Weight per item
0.5270
Related Documentation
