| Cutting Width (CW) | 5 mm | Tool Type | BLADES - FOR FACE GROOVING |
| Cutting Direction (HAND) | Right Hand | Body Material | Steel |
| Overall Length (OAL) | 140 mm | Functional Width (WF) | 13.6 mm |
| Work Piece Parting Diameter Maximum (CUTDIA) | 500 mm | Measurement Type | Metric |
| Application | | Face grooving | | Unit | M |
| Minimum Bore Diameter (DMIN) | 200 mm |
Product Features
| Family Description | Face grooving blade | FamilyName | EFPR/L |
| Remarks | Wrench (ECW**) for clamping insert should be ordered separately. For wrench (ECW**), click on "More Info". | BrandName | Tungaloy |
| COO | JAPAN |
Shipping Info
Weight per item
0.1230
Name
Face Groove/Turn Indexable Holders
FamilyName
EFPR/L
BrandName
Tungaloy
